18RK065 Cold rolled GO Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.7/50 loss(W/kg) |
Min.Induction(T)J800 |
|
18RK065 |
0.18 |
0.64 |
1.89 |
18RK065 Cold rolled GO Electrical steel typical mechanical property
|
Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
Number of bends |
Vickers Hardness |
Stacking factor |
Resistivity |
||||
|
L |
C |
L |
C |
L |
C |
L |
C |
HV1 |
||
|
345 |
402 |
324 |
342 |
13 |
42 |
44 |
14 |
201 |
0.953 |
52 |
18RK065 Cold rolled GO Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Transverse thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Flatness(%) |
Nominal width(mm) |
|
0.18 |
+0.010 |
+0.012 |
+0.010 |
+0.5 |
≤1.0 |
750-1270 |
18RK065 is a steel grade under BAOSTEEL Q/BQB standard. 18RK065 Cold rolled Grain-Oriented Electrical steel is Domain Refined type material. If you want 18RK065 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
Related product :20WTG1500 Cold rolled Grain-Oriented Electrical steel
