30WGP1600 Cold rolled GO Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.0/400 loss(W/kg) |
Min.Magnetic Polarization(T)J5000 |
Min. Lamination factory |
Min.Number of bends |
Density(kg/dm3) |
|
30WGP1600 |
0.30 |
16.00 |
1.62 |
0.98 |
3 |
7.60 |
30WGP1600 Cold rolled GO Electrical steel typical mechanical property
|
Yield strength (MPa) |
Tensile strength (MPa) |
Elongation (%) |
Vickers Hardness |
Stacking factor |
|||
|
L |
C |
L |
C |
L |
C |
HV1 |
|
|
420 |
430 |
520 |
530 |
16 |
18 |
190 |
0.98 |
30WGP1600 Cold rolled GO Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Transverse thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Flatness(%) |
Nominal width(mm) |
|
0.30 |
+0.015 |
≤0.012 |
+1.5 |
≤1.5 |
1000-1250 |
30WGP1600 is a steel grade under BAOSTEEL Q/BQB standard. 30WGP1600 Cold rolled Grain-Oriented Electrical steel series material. If you want 30WGP1600 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
