35Q155-Y Cold rolled GO Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.7/50 loss(W/kg) |
Min.Induction(T)J800 |
Min. Lamination factory |
|
35Q155-Y |
0.35 |
1.3 |
1.86 |
0.965 |
35Q155-Y Cold rolled GO Electrical steel typical mechanical property
|
Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
Number of bends |
Vickers Hardness |
Stacking factor |
Resistivity |
||||
|
L |
C |
L |
C |
L |
C |
L |
C |
HV1 |
||
|
369 |
405 |
347 |
365 |
13 |
42 |
20 |
6 |
180 |
0.980 |
53 |
35Q155-Y Cold rolled GO Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Transverse thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Flatness(%) |
Nominal width(mm) |
|
035 |
+0.010 |
+0.015 |
+0.012 |
+0.5 |
≤1.0 |
750-1270 |
35Q155-Y is a steel grade under BAOSTEEL Q/BQB standard. 35Q155-Y Cold rolled Grain-Oriented Electrical steel is Special coating type material. If you want 35Q155-Y GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
