35WW360 Cold rolled Non-Oriented Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.7/50 loss(W/kg) |
Min.Induction(T)J800 |
Min. Lamination factory |
Min. Number of Bends |
Conventional Density(kg/dm3) |
|
35WW360 |
0.35 |
3.32 |
1.65 |
0.95 |
3 |
7.65 |
35WW360 Cold rolled Non-Oriented Electrical steel typical electromagnetic properties
|
Core loss(W/kg) |
Magnetic Polarization(T) |
||||||
|
P1.0/50 |
P1.5/50 |
P1.0/60 |
P1.5/60 |
J1000 |
J2500 |
J5000 |
J10000 |
|
1.16 |
2.69 |
1.44 |
3.35 |
1.50 |
1.60 |
1.69 |
1.80 |
35WW360 Cold rolled Non-Oriented Electrical steel typical mechanical property
|
Yield strength (MPa) |
Tensile strength (MPa) |
Elongation (%) |
Vickers Hardness |
Number of bends |
Stacking factor |
||||
|
L |
C |
L |
C |
L |
C |
HV1 |
L |
C |
|
|
380 |
400 |
490 |
505 |
27 |
29 |
170 |
17 |
16 |
0.980 |
35WW360 Cold rolled Non-Oriented Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Transverse thickness deviation(mm) |
Nominal width(mm) |
|
0.35 |
+0.020 |
+0.010 |
+0.012 |
+0.015 |
700-1260 |
35WW360 is a steel grade under BAOSTEEL Q/BQB standard. 35WW360 Cold rolled Non-Oriented Electrical steel is CONVENTIONAL TYPE WW series material. If you want 35WW360 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
