B23P080 Cold rolled GO Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.7/50 loss(W/kg) |
Min.Induction(T)J800 |
|
B23P080 |
0.23 |
0.79 |
1.92 |
B23P080 Cold rolled GO Electrical steel typical electromagnetic properties
|
Core loss(W/kg) |
Induction(T) J800 |
|||
|
P1.7/50 |
P1.7/60 |
P1.5/50 |
P1.5/60 |
|
|
0.79 |
1.04 |
0.58 |
0.78 |
1.92 |
B23P080 Cold rolled GO Electrical steel typical mechanical property
|
Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
Number of bends |
Vickers Hardness |
Stacking factor |
Resistivity |
||||
|
L |
C |
L |
C |
L |
C |
L |
C |
HV1 |
||
|
354 |
401 |
331 |
346 |
14 |
42 |
32 |
11 |
205 |
0.953 |
53 |
B23P080 Cold rolled GO Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Transverse thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Flatness(%) |
Nominal width(mm) |
|
0.23 |
+0.010 |
+0.012 |
+0.010 |
+0.5 |
≤1.0 |
750-1270 |
B23P080 is a steel grade under BAOSTEEL Q/BQB standard. B23P080 Cold rolled Grain-Oriented Electrical steel is High permeability type material. If you want B23P080 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
