B27P085 Cold rolled Grain-Oriented Electrical steel

B27P085 Cold rolled GO Electrical steel properties:

Grade	Thickness (mm)	Max.Core 1.7/50 loss(W/kg)	Min.Induction(T)J800
B27P085	0.27	0.84	1.91

B27P085 Cold rolled GO Electrical steel typical electromagnetic properties

Core loss(W/kg)				Induction(T) J800
P1.7/50	P1.7/60	P1.5/50	P1.5/60	Induction(T) J800
0.84	1.12	0.62	0.84	1.91

B27P085 Cold rolled GO Electrical steel typical mechanical property

Tensile strength (MPa)		Yield strength (MPa)		Elongation (%)		Number of bends		Vickers Hardness	Stacking factor	Resistivity (x10-8) Ω·m
L	C	L	C	L	C	L	C	HV1	Stacking factor	Resistivity (x10-8) Ω·m
378	438	360	380	10	39	30	9	220	0.968	54

B27P085 Cold rolled GO Electrical steel dimension and shape tolerances

Nominal thickness(mm)	Nominal thickness tolerance(mm)	Longitudinal thickness deviation(mm)	Transverse thickness deviation(mm)	Width tolerance(Cut edge)(mm)	Flatness(%)	Nominal width(mm)
0.27	+0.010 -0.020	+0.015 0	+0.012 0	+0.5 0	≤1.0	750-1270

B27P085 is a steel grade under BAOSTEEL Q/BQB standard. B27P085 Cold rolled Grain-Oriented Electrical steel is High permeability type material. If you want B27P085 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
