B27P110-LM Cold rolled Grain-Oriented Electrical steel

B27P110-LM Cold rolled GO Electrical steel properties:

Grade	Thickness (mm)	Max.Core 1.7/50 loss(W/kg)	Min.Induction(T)	Min. Lamination factory
B27P110-LM	0.27	1.03	1.90	0.960

B27P110-LM Cold rolled GO Electrical steel typical mechanical property

Tensile strength (MPa)		Yield strength (MPa)		Elongation (%)		Number of bends		Vickers Hardness	Stacking factor	Resistivity (x10-8) Ω·m
L	C	L	C	L	C	L	C	HV1	Stacking factor	Resistivity (x10-8) Ω·m
378	438	360	380	10	39	30	9	220	0.968	54

B27P110-LM Cold rolled GO Electrical steel dimension and shape tolerances

Nominal thickness(mm)	Nominal thickness tolerance(mm)	Longitudinal thickness deviation(mm)	Transverse thickness deviation(mm)	Width tolerance(Cut edge)(mm)	Flatness(%)	Nominal width(mm)
0.27	+0.010 -0.020	+0.015 0	+0.012 0	+0.5 0	≤1.0	750-1270

B27P110-LM is a steel grade under BAOSTEEL Q/BQB standard. B27P110-LM Cold rolled Grain-Oriented Electrical steel is low magnetostriction type material. If you want B27P110-LM GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
