B30P090 Cold rolled Grain-Oriented Electrical steel

B30P090 Cold rolled GO Electrical steel properties:

Grade	Thickness (mm)	Max.Core 1.7/50 loss(W/kg)	Min.Induction(T)J800
B30P090	0.30	0.89	1.92

B30P090 Cold rolled GO Electrical steel typical electromagnetic properties

Core loss(W/kg)				Induction(T) J800
P1.7/50	P1.7/60	P1.5/50	P1.5/60	Induction(T) J800
0.89	1.19	0.67	0.91	1.92

B30P090 Cold rolled GO Electrical steel typical mechanical property

Tensile strength (MPa)		Yield strength (MPa)		Elongation (%)		Number of bends		Vickers Hardness	Stacking factor	Resistivity (x10-8) Ω·m
L	C	L	C	L	C	L	C	HV1	Stacking factor	Resistivity (x10-8) Ω·m
372	408	346	367	14	44	23	7	208	0.973	53

B30P090 Cold rolled GO Electrical steel dimension and shape tolerances

Nominal thickness(mm)	Nominal thickness tolerance(mm)	Longitudinal thickness deviation(mm)	Transverse thickness deviation(mm)	Width tolerance(Cut edge)(mm)	Flatness(%)	Nominal width(mm)
0.30	+0.010 -0.025	+0.015 0	+0.012 0	+0.5 0	≤1.0	750-1270

B30P090 is a steel grade under BAOSTEEL Q/BQB standard. B30P090 Cold rolled Grain-Oriented Electrical steel is High permeability type material. If you want B30P090 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
