B30R095-LM Cold rolled GO Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.7/50 loss(W/kg) |
Min.Induction(T) |
Min. Lamination factory |
|
B30R095-LM |
0.30 |
0.92 |
1.90 |
0.960 |
B30R095-LM Cold rolled GO Electrical steel typical mechanical property
|
Tensile strength (MPa) |
Yield strength (MPa) |
Elongation (%) |
Number of bends |
Vickers Hardness |
Stacking factor |
Resistivity |
||||
|
L |
C |
L |
C |
L |
C |
L |
C |
HV1 |
||
|
372 |
408 |
346 |
367 |
14 |
44 |
23 |
9 |
208 |
0.973 |
53 |
B30R095-LM Cold rolled GO Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Transverse thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Flatness(%) |
Nominal width(mm) |
|
0.30 |
+0.010 |
+0.025 |
+0.012 |
+0.5 |
≤1.0 |
750-1270 |
B30R095-LM is a steel grade under BAOSTEEL Q/BQB standard. B30R095-LM Cold rolled Grain-Oriented Electrical steel is low magnetostriction type material. If you want B30R095-LM GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
