B35AHV1700 Cold rolled GO Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.0/400 loss(W/kg) |
Min.Magnetic Polarization(T)J5000 |
Min. Lamination factory |
Min.Number of bends |
Density(kg/dm3) |
|
B35AHV1700 |
0.35 |
17.00 |
1.66 |
0.95 |
2 |
7.65 |
B35AHV1700 Cold rolled GO Electrical steel typical electromagnetic properties
|
Core loss(W/kg) |
Magnetic Ploarization(T) |
||||||||
|
P1.0/50 |
P1.5/50 |
P1.0/60 |
P1.5/60 |
P1.0/400 |
P1.0/800 |
J1000 |
J2500 |
J5000 |
J10000 |
|
0.93 |
2.08 |
1.14 |
2.57 |
16.00 |
47.00 |
1.50 |
1.60 |
1.68 |
1.80 |
B35AHV1700 Cold rolled GO Electrical steel typical mechanical property
|
Yield strength (MPa) |
Tensile strength (MPa) |
Elongation (%) |
Vickers Hardness |
Number of bends |
Stacking factor |
||||
|
L |
C |
L |
C |
L |
C |
HV1 |
L |
C |
|
|
397 |
410 |
518 |
533 |
19 |
20 |
210 |
10 |
10 |
0.985 |
B35AHV1700 Cold rolled GO Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Transverse thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Flatness(%) |
Nominal width(mm) |
|
0.35 |
+0.015 |
+0.010 |
+0.012 |
+1.5 |
≤1.5 |
900-1250 |
B35AHV1700 is a steel grade under BAOSTEEL Q/BQB standard. B35AHV1700 Cold rolled Grain-Oriented Electrical steel is High efficiency type AHV series material. If you want B35AHV1700 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
