B65A530 Cold rolled Non-Oriented Electrical steel properties:
|
Grade |
Thickness (mm) |
Max.Core 1.7/50 loss(W/kg) |
Min.Induction(T)J800 |
Min. Lamination factory |
Min. Number of Bends |
Conventional Density(kg/dm3) |
|
B65A530 |
0.65 |
5.20 |
1.68 |
0.97 |
10 |
7.70 |
B65A530 Cold rolled Non-Oriented Electrical steel typical electromagnetic properties
|
Core loss(W/kg) |
Magnetic Polarization(T) |
||||||
|
P1.0/50 |
P1.5/50 |
P1.0/60 |
P1.5/60 |
J1000 |
J2500 |
J5000 |
J10000 |
|
2.16 |
4.83 |
2.77 |
6.14 |
1.51 |
1.61 |
1.70 |
1.81 |
B65A530 Cold rolled Non-Oriented Electrical steel typical mechanical property
|
Yield strength (MPa) |
Tensile strength (MPa) |
Elongation (%) |
Vickers Hardness |
Number of bends |
Stacking factor |
||||
|
L |
C |
L |
C |
L |
C |
HV1 |
L |
C |
|
|
242 |
251 |
402 |
410 |
36 |
37 |
137 |
≥20 |
≥20 |
0.992 |
B65A530 Cold rolled Non-Oriented Electrical steel dimension and shape tolerances
|
Nominal thickness(mm) |
Nominal thickness tolerance(mm) |
Longitudinal thickness deviation(mm) |
Width tolerance(Cut edge)(mm) |
Transverse thickness deviation(mm) |
Nominal width(mm) |
|
0.65 |
+0.020 |
+0.020 |
+0.020 |
+0.025 |
700-1260 |
B65A530 is a steel grade under BAOSTEEL Q/BQB standard. B65A530 Cold rolled Non-Oriented Electrical steel is CONVENTIONAL type material. If you want B65A530 GO Electrical steel core loss,tensile strength, coating, using, curve, or other information, please contact JOIN WIN STEEL sales team.
